Depth Micrometer 0–22 In, 0.001 In, 4 Anvils, 6 Rods

Depth micrometer set delivers fast, repeatable depth measurements for grooves, steps, and holes with a clear mechanical readout and 0.001 in resolution. Built for machinists and metalworking pros, it combines a stable metal frame with smooth reference faces to reduce reading errors. Six standard rods extend the measuring range up to 22 in, while four interchangeable anvils help match different workpiece surfaces for consistent contact.

• Delivers 0.001 in resolution for precise depth readings on parts, slots, and recesses


• Includes 6 standard rods to configure a 0–22 in measuring range as jobs change


• Fits different workpieces with 4 anvils: 1 pointed, 1 flat, and 2 ball tips


• Reduces error with stainless-steel anvils and smooth reference faces for stable seating


• Stores safely in a hard case to keep components organized for shop or field work

When depth matters, a reliable micrometer saves time on rework and setup checks. This mechanical depth gauge is designed for quick, easy-to-read measurements on engine parts, precision components, sheet metal, and machined features—without relying on batteries or menus. Swap the anvils to match the surface, combine rods to reach the needed range, and keep everything protected in the included case between jobs. Grab yours today and keep accurate depth measurement ready at the bench or on-site.

• Measuring range: 0–22 in (with rods)


• Resolution: 0.001 in


• Accuracy: 0–0.2 in ±0.001 in; 0.2–1 in ±0.003 in


• Unit system: Imperial (non-switchable)


• Standard rod lengths: 6/5/4/3/2/1 in (152.4/127/101.6/76.2/50.8/25.4 mm)


• Measuring heads: 1 pointed tip, 1 flat tip, 2 ball tips


• Base dimensions: 3.89 x 0.61 x 0.96 in (99 x 15.5 x 24.5 mm)


• Product dimensions (without rod): 3.89 x 0.9 x 4.92 in (99 x 23 x 125 mm)


• Net weight: 1.28 lb (0.58 kg)


• In the box: depth micrometer, 6 rods, 4 anvils, instructions, hard case
