USB charger 2 x USB-C PD 65W GaN

LogiLink Compact double USB-C PD charger of 60W with GaN technology

Highly efficient USB-C wall charger with GaN technology for fast charging of smartphones, tablets, etc. The compact size makes it easy to carry anywhere.

Built-in GaN technology
By using gallium nitride (GaN) instead of silicon to manufacture the circuits you get higher performance in the form of faster chargers and higher efficiency, as well as smaller chargers for the size.

Advanced USB-C Power Delivery
With an output power of 60W it is possible to charge a variety of devices, everything from laptops to smartphones.
Check what the connected device requires for output power (W) on the charger.

PPS charging
PA0283 supports PPS (Programmable Power Supply) charging and real-time adjustment of the output power, depending on the charging status of the device, it delivers the maximum power.

Correct use of the PD function can only be guaranteed in combination with certified USB cables with E-Mark chipset.

Max power when charging:
USB-C 1: 5 V/3 A (15 W), 9 V/3 A (27 W), 12 V/3 A (36 W), 15 V/3 A (45 W), 20 V/3.25 A (65 W)
USB-C 2: 5 V/3 A (15 W), 9 V/3 A (27 W), 12 V/3 A (36 W), 15 V/3 A (45 W), 20 V/3.25 A (65 W)
PPS: 3.3–11 V/5 A
Max. total output power: 65 W

Specifications
- Connection: 2x USB-C port
- Supports PPS (Programmable Power Supply) charging and adjustment of output power in real time, depending on the charging status of the device, it delivers maximum power
- Conducts higher voltages than silicon-based chargers with better heat dissipation
- Input: 230 V AC, 50/60 Hz 2 A
- Output USB-C 1: 5 V/3 A (15 W), 9 V/3 A (27 W), 12 V/3 A (36 W), 15 V/3 A (45 W), 20 V /3.25 A (65 W), USB-C 2: 5 V/3 A (15 W), 9 V/3 A (27 W), 12 V/3 A (36 W), 15 V/3 A (45 W), 20 V/3.25 A (65 W)
- PPS: 3.3–11 V/5 A
- Max. total output power: 65W
- Protection against: Over current, over voltage, overheating and short circuit
- Compatible with most devices such as smartphones, tablets and more
- Operating temperature -10-40 ºC
- Storage temperature -20-80 ºC

Colour: White
Dimensions: 5.5 x 3.58 x 9.25 cm< /p>
