12V Hydraulic Power Unit, Single-Acting, 6 Qt 3200 PSI

12V hydraulic power unit delivers fast, reliable lifting for dump trailers and other single-acting remote hydraulic systems. Built around a 6-quart metal reservoir and a high-output motor, this pre-assembled hydraulic power pack supports power-up/gravity-down operation with solenoid control and a 15 ft handheld pendant for convenient operation from a safe distance. Relief-valve protection helps manage pressure for steadier performance during demanding work.

• Delivers quick power-up/gravity-down action for dump beds, stackers, and lifting platforms


• Includes a 15 ft handheld pendant and an extra SAE #6 connector for simplified setup


• Protects with an integrated relief valve to help reduce overpressure risk


• Fits many 12V DC remotely controlled single-acting hydraulic systems as a replacement unit


• Supports flexible mounting in horizontal or vertical positions with clockwise rotation

Designed for straightforward replacement and dependable daily use, this single-acting hydraulic pump unit arrives assembled, with simple wiring and clear operation. The metal tank is built to handle regular jobsite vibration and movement, while the 2.0 GPM flow helps shorten lift cycles when you need equipment ready without delays. Confirm your port pressure requirements and connector size before install, then connect, wire, and control lifting from the pendant. Grab yours today and get your hydraulic system back to work.

• System type: Single-acting (power-up / gravity-down)


• Voltage: DC 12V


• Power: 1.6 kW rated / 3.0 kW max


• Flow: 2.0 GPM


• Displacement: 1.1 cc/r


• Max relief valve setting (A port): 3200 PSI


• Max relief valve setting (B port): 1500 PSI


• Connector: SAE #6 ports


• Tank capacity: 6 L / 6 quart / 1.5 gal


• Tank material: Metal


• Control: Solenoid + handheld pendant


• Pendant length: 15 ft / 4.5 m


• Rated speed: 2850 R/min


• Duty cycle: 3 min


• Mounting: Horizontal or vertical


• Rotation: Clockwise
